HV Foil Winding Machine

Description

It is used to wind HV coils with foil strip. Total turns, segment turns and quantitative movement etc can be set via touch screen. It can realize laser locating original position and error correction. 100 sets of coil parameter can be called.

Main components

Foil decoiler, press deburring and cleaning device, insulation decoiler, welding system (with TIG160A argon arc welder) (Option), winding unit, correction system, laser device, pneumatic control unit, electric control unit
