| No. | Item | Parameters |
|---|---|---|
| 1 | Product scope | Copper/aluminum rectangular wire |
| 2 | Section area | 5~100 mm² (a production line with 3 sets of small strip device) |
| 3 | Lapping pitch | 10~32 mm, stepless adjustable |
| 4 | Lapping head rated speed | 800 rpm/min |
| 5 | Production speed | 0~600 rpm/min |
| 6 | Wrapping speed | 3.6m–20m/min |
| 7 | Max. Linear speed | About 17m/min |
| 8 | Paper Pad OD | 330 mm |
| 9 | Paper Pad ID | 75 mm |
| 10 | Paper Pad width | 10~32 mm |
| 11 | Paper thickness | 0.040~0.125 mm |
